Here is a point-by-point guide on how to use the Goldway UT4000 patient monitor motherboard, intended for qualified biomedical equipment technicians (BMETs).

Important Disclaimer: The motherboard is the core internal component. "Using" it refers to procedures for installation, testing, and troubleshooting by trained technicians. This is not a guide for clinical use by healthcare providers.

1. Pre-Installation and Safety Precautions

• Verify Compatibility: Confirm the Goldway replacement motherboard is explicitly compatible with your specific UT4000 monitor model and its existing hardware (e.g., display, parameter modules).

• Power Down and Disconnect: Completely power off the patient monitor. Disconnect it from AC mains power and remove any internal backup batteries.

• Electrostatic Discharge (ESD) Protection: Always wear an anti-static wrist strap and work on an ESD-safe mat. The motherboard contains highly sensitive components that can be easily damaged by static electricity.

• Prepare the Environment: Work in a clean, well-lit, and static-free area to avoid contamination or physical damage to the board or other internal components.

• Gather Documentation: Have the necessary technical documentation or service manuals for the UT4000 monitor available for reference.

2. Removal of the Old Motherboard (if replacing)

• Open the Chassis: Carefully remove the outer casing and any internal shields of the monitor according to the disassembly instructions.

• Document Connections: Before disconnecting anything, take clear photographs and note the positions of all cables, ribbon connectors, and wiring harnesses attached to the existing motherboard. This is crucial for correct reassembly.

• Disconnect Cables: Gently disconnect all cables from the old motherboard. Pay attention to locking mechanisms on connectors.

• Unscrew and Remove: Unscrew the motherboard from its mounting standoffs. Carefully lift the board straight out of the chassis, avoiding contact with other components.

3. Installation of the Motherboard

• Inspect the New Board: Visually inspect the new Goldway motherboard for any signs of physical damage, bent pins, or damaged connectors.

• Position and Secure: Align the new motherboard correctly with the mounting holes. Carefully lower it into place and secure it with the correct screws. Avoid flexing the board.

• Reconnect Cables: Using your pre-documentation (photos/notes), methodically reconnect all cables and wiring harnesses to their exact locations on the new motherboard. Ensure every connector is firmly and fully seated. Double-check ribbon cable orientations.

• Reassemble the Monitor: Once all connections are verified, reattach any internal shields and carefully reattach the monitor's outer casing.

4. Post-Installation Testing and Verification

• Initial Power On: Reconnect the monitor to AC power. Do not reconnect the internal battery yet. Power the unit on.

• Observe Start-Up: The device should perform a Power-On Self-Test (POST). Observe the boot process for any immediate error messages or failures.

• Perform Comprehensive Functional Tests: Test every parameter and function of the monitor to ensure the motherboard interfaces correctly with all modules:

  • Display: Check for a clear, full image with no artifacts.

  • ECG: Connect to a simulator and verify waveform quality and heart rate accuracy.

  • SpO₂: Use a probe tester or simulated finger to verify saturation reading and plethysmograph waveform.

  • NIBP: Run a calibration test with a pressure simulator to ensure accurate blood pressure readings.

  • Respiration & Temperature: Verify with appropriate simulators.

  • Alarms: Test all audible and visual alarms.

  • Connectivity: Test network (LAN) and data output ports (e.g., VGA, USB).

• Final Assembly: If all tests pass, power down, reconnect the internal backup battery, and fully reassemble the unit.

5. Documentation and Compliance

• Record the Service: Document the entire procedure in the device's service history log. Include the date, reason for service, part number of the new motherboard, and the results of all functional tests.

• Regulatory Compliance: Ensure the repair and testing process complies with relevant medical device regulations and hospital policies, confirming the device is safe and ready for clinical use.

Final Warning: This procedure must only be performed by qualified technical personnel. Incorrect installation can cause monitor malfunction, leading to incorrect patient data and a serious risk to patient safety.
